B301 Series Biological Microscope

  • Finite optical system
  • Monocular, binocular, trinocular model
  • New generation biological microscope for education and clinic
  • The built-in LED illumination system

Click the button below to contact us:


B301 series biological microscope uses a finite distance optical system. It is a kind of biological microscope. The observation effect of the product is compared with our B series products. The appearance design is the appearance design of B302, but it is smaller overall. There are three types of this product: monocular, binocular, and trinocular. The objective lens can be matched according to your needs.

Binocular Biological Microscope B301 Butterfly Head Binocular Microscope

| Features of B301 Series Biological Microscope

  • New Generation Biological Microscope for Education and Clinic.
  • Built-in LED Illumination System which can be powered with Power Bank, Laptop, and Vehicle Power Supply ensures being used anywhere and in any Condition.
  1. Brand New And Humanized Butterfly Binocular Head-Tubes Can Be 360° Rotated To Raise Observing Height 44mm Than Normal Tubes To Be More Convenient For Users With Different Height.
  1. Unique Observe Head and Integrative Stand to Ensure Stability.
  1. 5V-12V Low Voltage Input To Ensure Safe Use
  1. Built-in LED Illumination System Which Can Be  Powered with Power Bank, Laptop, and Vehicle Power Supply Ensuers Being Used Anywhere and Any Condition.
  1. Unique And Innovative Low Power Light-Reducing Objective (Optional) Ensures High Power And Low Power Objectives Interconverted Without Light Adjustment.
  1. A Humanized Storage Bin On The Stand Back Makes Moving And Items Storage, More Convenient.
  1. Observing Window Ensures Objective Magnification Can Be Watched From Back
  1. The Eyepiece Can Be Fixed in the tube to avoid the loss of the Eyepiece (Optional)

| Specifications of B301 Series Biological Microscope

EyepieceWF 10×-18 mm(pointer is optional)●●●●
WF 16×-13 mm○○○○
WF 10×-18 mm(non-adjustable,reticule 0.1 mm)
WF 10×-18 mm(adjustable,reticule 0.1 mm)
AchromaticObjective4X/0.10                 W.D.=18.6mm
10X/0.25                W.D.=6.5mm
40X/0.65 (S)             W.D.=0.47mm
100X/1.25 (Oil) (S)        W.D.=0.07mm
20X/0.40                 W-D.=1.75mm
60X/0.80(S)               W.D.=0.10mm
Plan Objective4X/0.10                   W.D.=14.5mm
10X/0.25                  W.D.=5.65mm
40X/0.65 (S)               W.D.=0.85mm
100X/1.25 (Oil) (S)          W.D.=0.07mm
Monocular HeadInclined 30°
Seidentopf Binocular HeadInclined 30°, Swiveling Siedentopf Head, IPD: 48-75mm
SeidentopfTrinocular HeadInclined 30°, Swiveling Siedentopf Head, IPD: 48-75mm, Light Distribution: 20:80
Focusing KnobsCoaxial Coarse and Fine Focusing KnobsTravel Range: 25mm, Scale: 2µm
Mechanical StageStage Size:125mm×115mm, Travel:35mm×75mm
CondenserAbbe N.A. 1.25(Iris Diaphragm)
Dark Field RingAvailable For 4×-40× Objective
0.5×(Focus Adjustable)
Base3W-LED Illumination Systems
External power adapter and data cable

Note: “●”In Table Is Standard outfits, “○” Is Optional Accessories.

Packing Size:440mm× 390mm× 280mm  Gross Weight: 5.8 kgs  Net Weight:4.4 kgs

| Applications of Biological Microscope

  • Medicine: Biological microscopes are used in medical laboratories to diagnose diseases, identify microorganisms, and study tissues and organs.
  • Biology research: Biological microscopes are used by biologists to study all aspects of life, from cells and molecules to organisms and ecosystems.
  • Education: Biological microscopes are used in schools and universities to teach students about biology and life sciences.
