MHB-3000 Digital Brinell Hardness Tester
- External digital display measuring micro-eyepiece, easy to measure, and the hardness value is directly displayed
- Traditional model, durable
- Suitable for cast iron, steel products, nonferrous metals soft alloys etc. Also suitable for some nonmetal materials such as rigid plastics and bakelite etc.
Click the button below to contact us:
Description
Brinell hardness test is a test method with the largest indentation in all hardness tests, which can reflect the comprehensive performance of materials. There are 3 types of Brinell Hardness Testers: DHB-3000, MHB-3000, and XHB-3000.
MHB-3000 Digital Brinell hardness tester is a unified product combining the precise mechanical structure and the load cell control system. The instrument adopts the motorized test force application without weights and uses a 0.5‰ accuracy compression sensor to feedback and the CPU control system to automatically compensate for the test force lost during the test. With an external digital measuring microscope, no need to check the table or input the diagonal of the indentation, MHB-3000 digital brinell hardness tester can directly show the hardness value, test force, dwell time, and indentation length. As long as press the eyepiece button after measuring the indentation length, it can automatically get the hardness value and show it on the screen, with precise reading and easy operation.
| Application Range of MHB-3000 Digital Brinell Hardness Tester
MHB-3000 digital brinell hardness testers are suitable for cast iron, steel products, nonferrous metals soft alloys etc. Also suitable for some nonmetal materials such as rigid plastics and bakelite etc.
| Technical Specification of MHB-3000 Digital Brinell Hardness Tester
| Model | MHB-3000 | |
| Test Force | kgf | 62.5kgf, 100kgf, 125kgf, 187.5kgf, 250kgf, 500kgf, 750kgf, 1000kgf, 1500kgf, 3000kgf |
| N | 612.9N, 980.7N, 1226N, 1839N, 2452N, 4903N, 7355N, 9807N, 14710N, 29420N | |
| Test Range | 3.18～653HBW | |
| Hardness Reading | LCD Display | |
| Hardness Resolution | 0.01HBW | |
| Microscope | 20× Digital Measuring Microscope | |
| Effective Field of View | 6mm | |
| Min. Measuring Unit | 0.001mm | |
| Dwell Time | 0~60s | |
| Max. Sample Height | 205mm | |
| Throat Depth | 135mm | |
| Power Supply | AC220V, 50Hz | |
| Execute Standard | ISO 6506, ASTM E10, JIS Z2243, GB/T 231.2 | |
| Dimension | 545×235×755mm, Packing Dimension: 650×435×1020mm | |
| Weight | Net Weight: 130kg, Gross Weight: 160kg | |
| Packing List of MHB-3000 Digital Brinell Hardness Tester
| Name | Qty | Name | Qty |
| Instrument Main Body | 1 set | 20× Digital Measuring Microscope | 1 pc |
| Φ2.5mm, Φ5mm, Φ10mm Ball Indenter | each 1 pc | Φ200mm Flat Anvil | 1 pc |
| Φ60mm Flat Anvil | 1 pc | Φ80mm V-shaped Anvil | 1 pc |
| Hardness Block 150~250 HBW 10/3000 | 1 pc | Hardness Block 150~250 HBW 5/750 | 1 pc |
| Fuse 2A | 2 pcs | Power Cable | 1 pc |
| Inner Hexagon Spanner 3mm | 1 pc | Anti-dust Cover | 1 pc |
| Usage Instruction Manual | 1 copy |
| Delivery and Package
The delivery time is 7-15 days when our products are in stock. If the product is not in stock, or the required quantity is relatively large, you need to communicate with our sales staff, and then confirm the specific delivery time. Products such as MHB-3000 digital brinell hardness testers are packed in export wooden boxes. The product will be fixed in a wooden box with screws and straps to prevent bump damage caused by shaking. A variety of transportation methods can be selected according to needs.
