Description
I. Introduction to Shoulder Joint Simulation Model Pro
Shoulder Joint Simulation Model Pro is a complete training model for shoulder arthroscopic surgery. It helps surgeons quickly familiarize themselves with the procedures and instruments used in minimally invasive shoulder surgery, providing realistic visual and tactile feedback during the procedure, allowing surgeons to learn better and faster.
II. Surgical Training Procedures
1. Shoulder Arthroscopy
(1) Shoulder Arthroscopy Exploration
(2) Shoulder Arthroscopy Rotator Cuff Repair
(3) Shoulder Arthroscopy Acromoplasty
(4) Shoulder Arthroscopy Adhesion Release
(5) Arthroscopy Coracoclavicular Fixation
(6) Joint Capsule Release
(7) Labral Repair
2. Shoulder Joint Anatomy Training
III. Shoulder Joint Simulation Model Pro
1. Specifications and Dimensions:
Shoulder Joint Dimensions: 27 * 26 * 34 CM
Base Support Dimensions: 24 * 35 * 40 CM
Total Dimensions: 47 * 27 * 40 CM (Beach Chair Position)
- Not limited by location; can be placed directly on a table.
- 1:1 realistic human anatomy, adult physique, based on real human imaging data. Joints are movable, featuring a complete shoulder joint anatomy: including the proximal humerus, clavicle, scapula, subscapularis, supraspinatus, infraspinatus, teres minor, superior transverse scapular ligament, coracoclavicular ligament, coracoacromial ligament, coracohumeral ligament, glenoid fossa, and joint capsule.
4. Skin thickness approximately 2mm, Shore A hardness A10±2, tactile feel close to that of a normal human body, allowing palpable bones and realistic surgical sensation. Allows for skin disinfection, surface marking, puncture, cutting, suturing, and establishing working channels.
5. Skin is made of platinum-coated silicone material, characterized by high stability and non-toxicity. RoHS official non-toxic testing certificate is available.
6. Muscles and ligaments: Proprietary platinum-coated silicone material, highly realistic in appearance, flexible and elastic with tension, tactile feel close to that of a normal human body, realistic surgical sensation, tendons can be cut and sutured.
7. The upper humerus and scapula are made of a unique biomimetic bone material with a density similar to human bone. It contains both cortical and cancellous bone structures, with different densities in the cortical and cancellous bone, allowing for surgical procedures such as grinding, drilling, osteotomy, screw placement, plate placement, and fixation. Drilling provides a realistic feel of hollowing out, and bone powder is visible. The bone is less prone to cracking, and the material does not easily adhere to the cutting tip. It features a 1:1 scale replica of human anatomical structure, with accurate bony landmarks, enabling clinical-grade surface localization.
8. The model supports X-ray/CT imaging, providing clear imaging results and clearly distinguishable bones, closely resembling the real human body. CT scans of the model clearly distinguish cortical and cancellous bone, with significant differences in CT values, allowing for more realistic surgical simulation.
9. The model includes movable joints and extendable muscles to simulate shoulder movement.
10. The skin, muscles, ligaments, and bones of the manipulable parts of the model are consumables, reusable, and easily replaceable.
11. Includes a base stand for stability and easy handling of the model. The rotating design allows for adjustable angles, accommodating beach chair and lateral positions, facilitating various surgical approaches and positions.
IV. Basic Configuration Requirements
1. One human shoulder joint segment: including skin, muscles, ligaments, and bone; replaceable.
2. One matching base stand
3. One flight case
4. One instruction manual
